Name: BW MicroClip XL Multi-Gas Detector
SKU: MCXL-XXXX-Y-XX
Availability: InStock

Description

BW MicroClip XL Multi-Gas Detector

Under this gas detector is the same bestselling BW MicroClip but has been redesigned and rebranded as the BW MicroClip XL Multi-Gas Detector and given a brand-new cutting-edge battery design, providing up to 18 hours of operation. Eight hours more than the preceding version.

The popularity of this portable gas monitor is not just due to its reliability, but also its lightweight, small design and single-button mode of operation, making it very easy to use, especially within confined spaces.

For a more robust solution, especially against the challenges of working in cold conditions, the BW MicroClip XL is ideal and comes with extended battery life.

You can configure the BW MicroClip XL gas detector to monitor combinations of the following: Hydrogen Sulphide (H2S), Carbon Monoxide (CO), Oxygen (O2) and Combustible LEL.

For more information, get in contact via the contact us form or call 02920 759 683.

Specifications

GAS	MEASURING RANGE	RESOLUTION
H2S	0 -100 ppm	1 ppm
CO	0 – 500 ppm	1 ppm
O2	0-30.0%	0.1%
COMBUSTIBLE GASES
	0-100% LEL	1%
	0-5.0% v/v	0.1%

Size	11.3 x 6.0 x 3.2 cm / 4.4 x 2.4 x 1.2 in
Weight	190 g / 6.7 oz
Temperature	-20 to +50°C / -4 to +122°F
Humidity	0% – 95% RH (non-condensing)
Alarms	Visual, vibrating, audible (95 dB) • Low, High, TWA, STEL, OL (over limit)
Tests	Audible/visual alarms on activation; sensors, battery and circuitry (continuous)
Typical Battery Life	18 hours; recharges in less than 6 hours Note: Approximately 20% capacity loss is normal with lithium polymer batteries after 500 charge cycles. Refer to the Operator’s Manual for additional information.
User Options	• Confidence beep • Set STEL interval • Sensor on/off • Latching alarms • Safe display mode • Stealth mode • Calibration lock • Auto zero on start up • O2 auto calibration on start up • Set bump test interval • Force bump test when overdue
Ratings	IP68 – up to 45 minutes at 1.2 m (Honeywell BW™ MicroClip XL and X3) EMI/RFI: Complies with EMC Directive 2004/108/EC
Certifications and Approvals	CSA: Class I, Div. 1, Gr. A, B, C, D ATEX: , II 1 G. Ex ia IIC T4 Ga IECEx: Ex ia IIC T4 Ga European Conformity KTL (Honeywell BW™ MicroClip X3 certification in progress)
Warranty	Full two‑year (Honeywell BW™ MicroClip XL) or three‑year (Honeywell BW™ MicroClip X3) warranty including all sensors Note: Battery is guaranteed to have 12 hour runtime during warranty period under normal operating temperature of 4°F / -20°C to 122°F / 50°C
Expected Service Lifetime	Five years including all sensors* (Honeywell BW™ MicroClip X3 only) *Note: Sensors do not contain consumable components and will typically reach the expected lifetime if used according to the instructions in the user manual. Please note that poisoned sensors are not covered by warranty.
